Synchronize Spur Gear Hobbing Machine Model:- SSHL - 2
| Max. Shaft Dia. | 18 mm dia. |
| Cutting Length | 1200 mm |
| PITCH Capacity | Max. 1.25 Module, 20 D.P. |
| Nos. of TEETH cut by Std. & Extra gear | 6 to 102 Teeth all Nos. & 103 to 230 Teeth with some 'odd Nos. lapsed'. |
| Work SPINDLE size | 13,16,19 & 22 mm as per demand |
| HELIX ANGLE for Cutter | 5 degree max. for spur gear only |
| SHIFTING of Hob Spindle | 15 mm Liner Movement |
| REVOLUTION of Hob spindle. | 310 to 1500 RPM, 16 step High speed available on request. |
| FEED per Rev. of work | 0.063 to 1 mm, 13 step |
| ELECTRICAL Load | 0.8 KW., 3 Phase |
| Shipping Dimension & Weight | 2000x800x1400 mm, 550 Kg. Approx. |
